JAE Japan Aviation Electronics Industry, Ltd.
FI-W9P-HFE-E1500
1.25mm pitch, Board-to-Cable, Standard type, 9 pos., Board side receptacle
Number of Positions: 9 pos.
Number of Rows: 2
Contact Pitch: 1.25 mm
Rated Voltage: 200V
Rated Current: 1A
Operating Temperature Range: -40c to +80C
Connector Type: Board side receptacle
Connector Style: Right angle
PCB Mounting Method: Soldering (SMT)
Material of Contact: Copper alloy
Finish of Contact in Connecting Area: Gold plating over Nickel
Finish of Contact in PCB Mounting Area: Tin or Tin-alloy plating over Nickel
Material of Housing: Glass filled PPS (UL94V-0)
Datenblatt:
FIW9PHFE.pdf
€
1
.07*
