Ultra Low Power 1-Bit 32 kHz RTC
- Supply current typically 390 nA at 3V
- 50 ns access time with 50 pF load capacitance
- Fully operational from 1.2V to 5.5V
- No busy states or danger of a clock update while accessing
- Serial communication on one line of a standard parallel data bus or over a conventional 3 wire serial interface
- Interface compatible with both Intel and Motorola
- Seconds, minutes, hours, day of month, month, year, week day and week number in BCD format
- Leap year and week number correction
- Time set lock mode to prevent unauthorized setting of the current time or date
- Oscillator stability 0.3 ppm / volt
- No external capacitor needed
- Frequency measurement and test modes
- Temperature range: -40°C to +85°C
- On request extended temperature range, -40°C to +125°C
- Pin compatible with the V3021
- Maximum voltage at VDD VDDmax VSS + 7.0V
- Minimun voltage at VDD VDDmin VSS – 0.3V
- Maximum voltage at any signal pin Vmax VDD + 0.3V
- Minimum voltage at any signal pin Vmin VSS – 0.3V
- Logic supply voltage VDD 1.2 to 5.5 V
Datenblatt:
V3020.pdf
Beschreibung: Single-Chip DVB Satellite Receiver
The new single-chip satellite receivers integrate VLSI's true variable-rate QPSK (Quadrature Phase Shift Keying) A phase modulation technique that transmits two bits in four modulation states. See PSK and phase modulation. demodulation and forward error correction A communications technique that can correct bad data on the receiving end. Before transmission, the data are processed through an algorithm that adds extra bits for error correction. If the transmitted message is received in error, the correction bits are used to repair it. (FEC See forward error correction.
FEC - Forward Error Correction ) functions for existing and future digital video set-top box applications. The VES1789 operates anywhere between 1 and 60 MHz and the pin-compatible VES1790 version has a broader operational range of 1 MHz up to 90 MHz. Both chips are identical in all other performance and physical specifications.
High Side Switch
Number of Outputs: 4
Ratio - Input:Output: 1:1
Output Configuration: High Side
Output Type: N-Channel
Interface: On/Off
Voltage - Load: 10V to 36V
Current - Output: 700mA
Rds On (Typ): 200mOhm
Input Type: Non-Inverting
Features: Status Flag
Fault Protection: Current Limiting (Fixed), Over Temperature
Operating Temperature: -40C to 125C
Datenblatt:
VN340SP.pdf
High-side driver with MultiSense analog feedback for automotive applications
Number of Drivers: 1 Driver
Number of Outputs: 1 Output
Supply Voltage - Min: 4 V
Supply Voltage - Max: 28 V
Off Time - Max: 40 us
Configuration: Single
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 150 C
Datenblatt:
VN7140AS.pdf
High-Side Driver 36V / 0.7A
Number of Outputs: 1 Output
Output Current: 700 mA
On Resistance - Max: 135 mOhms
On Time - Max: 10 us
Off Time - Max: 40 us
Operating Supply Voltage: 36 V
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 150 C
Datenblatt:
VN800PS.pdf
Double channel high side driver for automotive applications
Number of Drivers: 2 Driver
Configuration: Non-Inverting
Supply Voltage - Max: 28 V
Supply Voltage - Min: 4.5 V
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 150 C
Qualification: AEC-Q100
Maximum Turn-Off Delay Time: 40000 ns
Maximum Turn-On Delay Time: 20000 ns
Operating Supply Current: 6 mA
Datenblatt:
VND5E050J.pdf
Double Channel High Side Driver
Number of Outputs: 2 Output
Output Current: 5 A
On Resistance - Max: 160 mOhms
Operating Supply Voltage: 5.5 V to 36 V
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 150 C
Datenblatt:
VND810.pdf
Dual Channel Multirate Signal Conditioner and Retimer
- Dual clock and data recovery architecture for GbE and Fibre Channel applications
- FibreTimer™ configurable clock recovery unit (CRU): repeater, retimer, or bypassed
- Programmable input signal equalization, output de-emphasis, and output drive levels Analog signal detect and protocol monitor indicators
- Optional half-rate SGMII clock and repeated reference clock output
Datenblatt:
VSC8228.pdf
