HD...

Hitachi

HD38980C

Beschreibung: Digital Clock With Internal Fluoresent Display Driver

€ 8 .00*

Hitachi

HD4074019S

Beschreibung: CMOS 4-BIT SINGLE-CHIP MICROCOMPUTERS Datenblatt: HD4074019.pdf

€ 17 .50*

Hitachi

HD4074720S

Beschreibung: 4-BIT SINGLE-CHIP MICROCOMPUTER Datenblatt: HD4074720.pdf

€ 17 .50*

Hitachi

HD44004

Beschreibung: Analog/Zeitsteuer-IC

€ 0 .70*

Hitachi

HD61102

Beschreibung: Dot Matrix Liquid Crystal Graphic Display Column Driver Datenblatt: HD61102.pdf

€ 10 .00*

Hitachi

HD61830A00

LCDC (LCD Timing Controller) - Dot matrix liquid crystal graphic display controller - Display control capacity - Graphic mode: 512k dots - Character mode: 4096 characters (212 characters) - Internal character generator ROM: 7360 bits - 160 types of 5 x 7 dot characters - 32 types of 5 x 11 dot characters - Total 192 characters - Can be extended to 256 characters (4 kbytes max.) with external ROM - Interfaces to 8-bit MPU - Low power dissipation - Power supply: Single +5 V +-10% Datenblatt: HD61830A00.pdf

€ 2 .80*

Hitachi

HD6321P

PIA (Peripheral Interface Adapter) Clock Frequency: 1.0MHz Supply Voltage: 5VDC Output Current Max.: 10mA Power Dissipation: 260mW Operating Temprature: -20C to +75C Datenblatt: HD6321.pdf

€ 7 .00*

Hitachi

HD637A01V0P

Beschreibung: 8-Bit Single Chip Microcomputer Datenblatt: HD637A01.pdf

€ 25 .00*

Hitachi

HD63B01V1L12P

0.3-7 V, CMOS microcomputer unit - Bus Timing: 2MHz - Up to 65k Words Address Space - Bit Manipulation - Bit Test Instruction Datenblatt: HD63B01V1.pdf

€ 11 .00*

Hitachi

HD63B03RP

1MHz CMOS Micro Processing Unit (MPU) Datenblatt: HD63B03.pdf

€ 8 .13*

Hitachi

HD63B03XP

Beschreibung: 1MHz CMOS Micro Processing Unit (MPU) Datenblatt: HD63B03XP.pdf

€ 20 .00*

Hitachi

HD63B03YP

Beschreibung: 1MHz CMOS Micro Processing Unit (MPU) Datenblatt: HD63B03YP.pdf

€ 16 .70*

Hitachi

HD63B09EP

Beschreibung: 8-Bit Microprocessor Datenblatt: HD63B09P.pdf

€ 7 .00*

Hitachi

HD63B09P

Beschreibung: 8-Bit Microprocessor Datenblatt: HD63B09P.pdf

€ 10 .00*

Hitachi

HD63C09EP

Beschreibung: 3MHz V(cc/in): -0.3 to +7.0V CMOS MPU (micro processing unit) Datenblatt: HD63C09.pdf

€ 9 .00*

Renesas

HD6412321VF25V

16-Bit Single-Chip Microcomputer Interface: SCI Watchdog Timer: Yes Max Frequency: 25MHz Memory Type: ROMless Data Bus Width: 16b RAM Size: 4KB Number of Programmable I/O: 86 Number of Timers/Counters: 8 Max Supply Voltage: 3.6V Min Supply Voltage: 2.7V Operating Supply Voltage: 3.3V Max Operating Temperature: 85°C Min Operating Temperature: -40°C data sheet: HD6412321.pdf

€ 9 .60*

Renesas

HD6412392F20V

Single-chip Microcomputer with the internal 32-bit H8S/2000 CPU Core - Bus width: 16 bit - ROM Size: 0 KByte - RAM Size: 512 Byte - T(A)max: 70 °C - T(A)min: 0 °C - ROM-Type: ROMLESS - max Timer Resol: 16 bit - Frequency (max): 16 MHz - max No.Timer: 5 - SPI No.: 1 - max No.ADC: 8 channels - max ADC Resol.: 10 bit - U(cc) min: 2.7 V - U(cc) max: 5.5 V Datenblatt: HD6412392F20V.pdf

€ 10 .00*

Hitachi

HD6417032TE16

Beschreibung: Romless, 2 to 16,6MHz, SuperH™ RISC Engine Datenblatt: HD6417032.pdf

€ 15 .00*

Hitachi

HD6417708R100A

Beschreibung: Hitachi SuperH™ RISC engine Datenblatt: HD6417708R100A.pdf

€ 12 .50*

Hitachi

HD6417750VF128

Beschreibung: 32-Bit RISC Microcomputer Datenblatt: HD6417750.pdf

€ 10 .00*

Hitachi

HD64465BP

Windows® CE Intelligent Peripheral Controller - Supports Hitachi SH-4/SH7709/SH3-DSP family of CPUs with bus speeds from 15 MHz up to 66 MHz. - Supports STANDBY mode when CKIO is stopped. - Memory mapped on area 4 of SH4/SH7709/SH3DSP for internal registers - 3.3 V-CMOS interface - 32 - bit data interface - PCMCIA PC card standard v2.1 compliant - Supports dual PCMCIA memory or IO cards at SH4/SH7709/SH3-DSP area 5 and area 6 - 8- or 16-bit PCMCIA interface support - Mixed voltage (3.3V or 5V) operation is fully supported for PCMCIA address, data and control signals. - Supports TI TPS2206 serial interface - Supports STANDBY mode Datenblatt: HD64465.pdf

€ 11 .00*

Hitachi

HD6473042F10

Beschreibung: High-Performance 16 Bit Microcontroller Datenblatt: HD6473042F.pdf

€ 17 .50*

Hitachi

HD6473048SVFI8

Beschreibung: Single-Chip Microcomputer H8/3048 Series Datenblatt: HD6473048.pdf

€ 9 .00*

Renesas

HD64F3062BFBL25V

Beschreibung: 16-Bit Single-Chip Microcomputer H8 Family/H8/300H Series Datenblatt: HD64F3062BF.pdf

€ 9 .00*

Renesas

HD64F3064BF25V

16-Bit Single-Chip Microcomputer Program memory: Flash memory CPU: H8/300H (16-bit) Max. Frequency: 25 MHz External Interrupt Pins: 7 8-bit Timers: 4 ch 16-bit Timers: 3 ch Watchdog Timers: 1 ch A/D Converters: 10-bit x 8 ch D/A Converters: 8-bit x 2 ch Operating Temperature: -20 to 75 Grad Datenblatt: HD64F3064B.pdf

€ 19 .00*

Renesas

HD64F3337SF16V

Beschreibung: Single–Chip Microcomputer H8/3337, F-ZTAT Datenblatt: HD64F3337SF16V.pdf

€ 10 .00*

Renesas

HD64F3337YFJ16V

Single–Chip Microcomputer H8/3337, F-ZTAT • Two-way general register configuration • Eight 16-bit registers, or Sixteen 8-bit registers • Maximum clock rate (ø clock): 16 MHz at 5 V, 12MHz at 4 V or 10 MHz at 3 V • 8- or 16-bit register-register add/subtract: 125 ns (16 MHz), 167 ns (12MHz), 200 ns (10 MHz) • 8 × 8-bit multiply: 875 ns (16 MHz), 1167 ns (12MHz), 1400 ns (10 MHz) • 16 ÷ 8-bit divide: 875 ns (16 MHz), 1167 ns (12MHz), 1400 ns (10 MHz) • Instruction length: 2 or 4 bytes • Register-register arithmetic and logic operations • MOV instruction for data transfer between registers and memory • Multiply instruction (8 bits × 8 bits) • Divide instruction (16 bits ÷ 8 bits) • Bit-accumulator instructions • Register-indirect specification of bit positions Datenblatt: HD64F3337YFJ16V.pdf

€ 6 .50*
