RT...

TE Tyco Electronics

RT315012

12VDC Power PCB Relay 1 POLE - 12A, Gold plated Relay Contact Form: 1 Form C (SPDT-NO, NC) Contact Current Rating: 16 A Voltage Rating (VAC): 400V Coil Voltage DC: 12V Coil Current: 33.3 mA Coil Resistance: 360 Ohm Contact Material Silver Nickel 90/10/Gold Plated Operating Temperature: -40 to 85 C Product Dimensions: 29 x 12.7 x 15.7 mm Datenblatt: RT315012.pdf

€ 3 .25*

Schrack

RT334012

Beschreibung: 12VDC Power PCB Relay RT1 Datenblatt: RT334012.pdf

€ 3 .50*

TE Tyco Electronics

RT33K012

General Purpose Relays Relay Contact Form: 1 Form A (SPST-NO) Switching Voltage: 250 VAC Contact Current Rating: 16 A Contact Termination: Solder Pin Mounting Style: Through Hole Coil Type: Non-Latching Coil Voltage: 12 VDC Coil Resistance: 360 Ohms Power Consumption: 400 mW Contact Material: Silver Nickel (AgNi) Datenblatt: RT33K012.pdf

€ 1 .90*

TE Tyco Electronics

RT424012

Power PCB Relay 12VDC Tyco-article-number: 6-1393243-3 Coil Voltage: 12 VDC Relay Contact Form: 2 Form C (DPDT-NO, NC) Contact Current Rating: 8 A Contact Termination: Solder Pin Mounting Style: Through Hole Switching Voltage: 250 VAC Coil Termination: Solder Pin Coil Type: Non-Latching Coil Resistance: 360 Ohms Coil Current: 33.3 mA Maximum Switching Current: 15 A Power Consumption: 400 mW Contact Material: Silver Nickel (AgNi) Height: 15.7 mm Length: 29 mm Width: 12.7 mm Datenblatt: RT424.pdf

€ 2 .50*

tyco

RT424F05

5VDC Power PCB Relay RT2 bistable 250VAC/8A Product: Power Relays Coil Voltage: 5 VDC Relay Contact Form: 2 Form C (DPDT-NO, NC) Contact Current Rating: 8 A Contact Termination: Solder Pin Mounting Style: Through Hole Switching Voltage: 250 VAC Maximum Switching Current: 15 A Coil Type: Dual Coil Latching Contact Material: Silver Nickel (AgNi) Height: 15.7 mm Length: 29 mm Width: 12.7 mm Unit Weight: 13 g Datenblatt: RT424F05.pdf

€ 2 .50*

tyco

RT424F12

General Purpose Relays - Product: Slim Form Relays - Coil Voltage: 12 VDC - Relay Contact Form: 2 Form C (DPDT-NO, NC) - Contact Current Rating: 10A - Contact Termination: Solder Pin - Mounting Style: Through Hole - Switching Voltage: 250 VAC - Coil Termination: Solder Pin - Coil Type: Dual Coil Latching - Coil Resistance: 240 Ohms - Contact Material: Silver Nickel (AgNi) - Series: RT2 Bistable - Height: 15.7 mm - Length: 29 mm - Width: 12.7 mm - Maximum Switching Current: 15 A - Power Consumption: 600 mW - Unit Weight: 13 g - Part Aliases: 5-1393243-4 Datenblatt: RT424F12.pdf

€ 1 .50*
